Red-finish fire alarm boxes (FAB) and control panels — hinge cover with plexiglass dead front, cam lock, and panelboard bus. Sizes 8×8 to 24×20, indoor or weatherproof, with fused disconnect (FAB-D) options.
Don’t see your exact size, material, or model? Add it in the notes above — we’ll quote it as a custom order.
Added ✓ — open the cart (top right) to review or send.Neutral bars available on request · Other sizes & configurations on request · $100.00 minimum order
Nav-Tech fire alarm boxes (FAB) house fire alarm control equipment in a red-finish hinge cover enclosure with a cam lock and Cat. 45 key. Each box includes a plexiglass dead front safety cover, a hinged main door and hinged inner access door, panelboard bus bar construction, and main lug line provisions. Boxes are finished in an electrostatically applied red powder coat and are available in indoor or weatherproof construction, with fused disconnect (FAB-D) versions available.
| Catalog # | Dimensions (H×W×D) | Amperage | Circuits |
|---|---|---|---|
| FAB 884 | 8×8×4″ | 30A | 4 |
| FAB 1284 | 12×8×4″ | 60A | 3 |
| FAB 12124 | 12×12×4″ | 30A | 6 |
| FAB 16164 | 16×16×4″ | 30A | 8 |
| FAB 24204 | 24×20×4″ | 30A | 12 |
Other sizes and configurations, including fused disconnect FAB-D panels, are available on request. See the spec sheets in the Downloads tab.
All fire alarm spec sheets are also on the Specifications page.
Tell us the size, circuit count, and whether you need a disconnect, and we'll quote it. Drawings, samples, and engineering support on every project.
